A practical perspective on railway-induced ground-borne noise and vibrations

The railway operation requires high safety, reliability, availability and passenger comfort with low maintenance efforts in order to be successful in the competitive market with other means of transport. Nevertheless, it also needs the acceptance of the public, for which the environmental impact should be minimised. Over the last few decades, there has been a growing interest in the understanding and prediction of railway-induced ground-borne vibration and noise amongst geotechnical and railway engineering practitioners.

Ground-borne vibrations are generated primarily due to the rail-wheel interaction, which may also result in ground-borne noise in the buildings/dwellings located in close proximity of railway tracks. There are different factors influencing the vibration amplitude including, but not limited to, ground conditions and damping characteristics; type and number of trains; train speed; track configurations; level crossings and so on. Predicting railway vibrations is an inherently complex task involving numerous uncertainties, especially when performing such analysis over a large area of train trajectory.

Adverse environmental effects have prompted several researchers and practitioners to study railway ground-borne vibrations and noise. It started with experimental and empirical methods in the 1990s. Based on these results, analytical and numerical methods have been developed and calibrated. Numerical approaches are meanwhile state-of-the-art, with the availability of more advanced computational capacities.

Current challenges

In general, one can distinguish two different categories regarding railway vibrations. Firstly, the effect of vibration on the surrounding environment generated by freight and passenger trains (conventional railway traffic); secondly, cyclic-dynamic impact through the vibration induced by high-speed trains or train speed increase in conventional railway traffic, as shown in Figure 1.

Cyclic-Dynamic impact is nowadays considered a priority when designing high-speed rail networks or dealing with an increase in train speed, especially on earth structures. This is because the interaction between the track and the subsoil (points 0 and 1 in Figure 1) should meet the requirements regarding serviceability and stability. If the operational train speed exceeds the surface Rayleigh wave speed in soil, critical train speed phenomenon would occur. This will amplify the generated deformations, causing damage to railway tracks or set a demand for additional maintenance influencing operation.

Environmental impact includes both the annoyance to residents living in the dwelling houses or working in the office buildings in the vicinity of railway tracks; as well as the damage to the inflicted offices or residential buildings by generated vibrations. These effects can be described through propagation path before reaching a dwelling or building (points 1 and 2 in Figure 1), on foundation level (point 3 in Figure 1), and on different floor levels (points 4 and 5 in Figure 1).

Examples of standards/guidelines that are employed to assess vibration effect include Dutch policy rules of track vibration (in Dutch: BTS), FTA-VA-90-1003-06 in the USA, DIN 4150-2 and DIN 4150-3 in Germany, BS 6472-1 in the UK, SS 460 4861 in Sweden, and NS 8176 in Norway.

First, practical approaches regarding the aforementioned effects shall be presented. Subsequently, a brief explanation as to how an abatement measure assessment works will be provided.

Figure 1 – Cyclic-dynamic phenomenon and environmental impact due to railway-induced vibration and noise.

Practical approaches

Along with other researchers and practitioners, Arcadis has been actively involved in railway-induced vibration and noise projects over the past decades. These include problems related to both cyclic-dynamic phenomenon and environmental impact. A brief summary of current approaches follows here, in which the focus is given to vibration problems.

Cyclic-dynamic impact

It is of importance to ensure that maximum operational speed could be achieved without damaging railway tracks due to exceeding threshold displacements, bumping effects and subsequently, inflicting disturbance to passengers, extra maintenance costs and operation of a line under the desired design train speed. This dictates that the cyclic-dynamic impact of track system and subsoils is to be assessed so as to fulfil the requirements concerning safety, reliability, operation and maintenance of high-speed rail. It is commonly accepted that the Rayleigh wave speed associated with generated vibration is identified as being the criterion to be achieved to mitigate the risk of amplifications of ground movements and deterioration of the track system. This is meanwhile state-of-the-art and acknowledged by railway authorities. However, from ongoing projects in different countries such as Germany, China and the Netherlands, it seems that the ultimate criterion is dynamic displacements which should be considered along with Rayleigh wave speed to limit maintenance efforts and to increase passenger comfort. A methodology for assessing cyclic-dynamic impact is shown in Figure 2.

Figure 2 – An overview of the process for performing a cyclic-dynamic impact assessment¹

Environmental impact

Dealing with a huge amount of data within a certain distance of a project, for instance, along a railway track of tens of kilometres in length, is amongst the most challenging tasks in existing projects. This data includes the structural characteristics of house dwelling and their types (monument or modern building), various ground conditions as well as vibration characteristics of the railway line. For example, all GIS-related information concerning the dwelling houses or office buildings positioned along the railway track are being processed and dealt with individually. Moreover, the superstructure and ground conditions are characterised along the railway track. For this purpose, cooperation of geotechnical, railway, environmental and GIS experts is employed. In parallel, measurement campaigns are carried out in order to assess the strength of vibrations generated by passenger and/or freight trains along and perpendicular to railway tracks. After having processed all GIS-related information as well as measurement data, one should address issues with annoyance owing to vibrations at each single property along the track. For this purpose, through analytical/empirical methods along with numerical approaches, maximum vibration levels at each single property along the track are determined and identified. Subsequently, an appraisal process is used to ensure the vibrations are within the threshold levels. In the case of exceedance of threshold values, a thorough abatement measure assessment is to be performed. A methodology for assessing environmental impact is shown in Figure 3.

Figure 3 – An overview of the process for performing an environmental impact assessment¹

Abatement measures

After having predicted the ground-borne vibrations, one could make a comparison between the obtained results and the allowable threshold values defined by the standards and regulation at the considered location. In the Netherlands, the threshold vibration levels for each single property positioned along the railway track are determined based on BTS. This is carried out based on determination of the maximum vibration level (Vmax) recorded at the location of a property, and the average vibration level (Vper) based on measurements during a certain period of time through the passage of trains. Once the threshold levels of Vmax or Vper defined based on BTS are exceeded, an abatement measure assessment is to be performed.

Vibration abatement measures are categorised in three different groups, reflecting the measures at the source of vibration; the measures through the propagation path which are used between the vibration source and receiver; and the measures at the receiver. In practice, the following criteria are employed for performing a thorough abatement measure assessment:

• Effectiveness of the measure for the frequency range of the problem
• Suitability of the measure to the existing working space
• Practical application of the measure for the considered area
• Maintenance of the measure expected/required
• Robustness of the measure
• Possible costs of applying the measure.

Conclusions

Railway-induced vibration and noise assessments involve dealing with numerous uncertainties. Arcadis, along with other researches and practitioners, has attempted to contribute to more rigorous approaches to minimise these uncertainties over the last two decades. In this article, two main challenges with simple practical methodologies have been provided; which can be employed to help practitioners address such problems. 

References:

1. In some projects, numerical analyses are also employed in the first place in order to determine the vibration and/or displacement levels.
